Sealant Cartridge Yield
The following table shows the estimated linear metreage of sealant, depending on joint width and depth. The yield is based on a standard 300ml cartridge; an adjustment would need to be made for cartridges of other volumes. Look down the table to find the expected joint width, then across to expected depth. The value shown at the intersection is the estimated length in metres. As an example, a cartridge would yield 6.25m if used to fill a joint of 8mm width, and 6mm depth.
| Joint Width |
Joint Depth | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 5mm | 6mm | 7mm | 8mm | 9mm | 10mm | 11mm | 12mm | 13mm | 14mm | 15mm | |
| 5mm | 12.00 | 10.00 | 8.57 | 7.50 | 6.67 | 6.00 | 5.45 | 5.00 | 4.62 | 4.29 | 4.00 |
| 6mm | 10.00 | 8.33 | 7.14 | 6.25 | 5.56 | 5.00 | 4.55 | 4.17 | 3.85 | 3.57 | 3.33 |
| 7mm | 8.57 | 7.14 | 6.12 | 5.36 | 4.76 | 4.29 | 3.90 | 3.57 | 3.30 | 3.06 | 2.86 |
| 8mm | 7.50 | 6.25 | 5.36 | 4.69 | 4.17 | 3.75 | 3.41 | 3.13 | 2.88 | 2.68 | 2.50 |
| 9mm | 6.67 | 5.56 | 4.76 | 4.17 | 3.70 | 3.33 | 3.03 | 2.78 | 2.56 | 2.38 | 2.22 |
| 10mm | 6.00 | 5.00 | 4.29 | 3.75 | 3.33 | 3.00 | 2.73 | 2.50 | 2.31 | 2.14 | 2.00 |
| 11mm | 5.45 | 4.55 | 3.90 | 3.41 | 3.03 | 2.73 | 2.48 | 2.27 | 2.10 | 1.95 | 1.82 |
| 12mm | 5.00 | 4.17 | 3.57 | 3.13 | 2.78 | 2.50 | 2.27 | 2.08 | 1.92 | 1.79 | 1.67 |
| 13mm | 4.62 | 3.85 | 3.30 | 2.88 | 2.56 | 2.31 | 2.10 | 1.92 | 1.78 | 1.65 | 1.54 |
| 14mm | 4.29 | 3.57 | 3.06 | 2.68 | 2.38 | 2.14 | 1.95 | 1.79 | 1.65 | 1.53 | 1.43 |
| 15mm | 4.00 | 3.33 | 2.86 | 2.50 | 2.22 | 2.00 | 1.82 | 1.67 | 1.54 | 1.43 | 1.33 |
| 16mm | 3.75 | 3.13 | 2.68 | 2.34 | 2.08 | 1.88 | 1.70 | 1.56 | 1.44 | 1.34 | 1.25 |
| 17mm | 3.53 | 2.94 | 2.52 | 2.21 | 1.96 | 1.76 | 1.60 | 1.47 | 1.36 | 1.26 | 1.18 |
| 18mm | 3.33 | 2.78 | 2.38 | 2.08 | 1.85 | 1.67 | 1.52 | 1.39 | 1.28 | 1.19 | 1.11 |
| 19mm | 3.16 | 2.63 | 2.26 | 1.97 | 1.75 | 1.58 | 1.44 | 1.32 | 1.21 | 1.13 | 1.05 |
| 20mm | 3.00 | 2.50 | 2.14 | 1.88 | 1.67 | 1.50 | 1.36 | 1.25 | 1.15 | 1.07 | 1.00 |
| 21mm | 2.86 | 2.38 | 2.04 | 1.79 | 1.59 | 1.43 | 1.30 | 1.19 | 1.10 | 1.02 | 0.95 |
| 22mm | 2.73 | 2.27 | 1.95 | 1.70 | 1.52 | 1.36 | 1.24 | 1.14 | 1.05 | 0.97 | 0.91 |
| 23mm | 2.61 | 2.17 | 1.86 | 1.63 | 1.45 | 1.30 | 1.19 | 1.09 | 1.00 | 0.93 | 0.87 |
| 24mm | 2.50 | 2.08 | 1.79 | 1.56 | 1.39 | 1.25 | 1.14 | 1.04 | 0.96 | 0.89 | 0.83 |
| 25mm | 2.40 | 2.00 | 1.71 | 1.50 | 1.33 | 1.20 | 1.09 | 1.00 | 0.92 | 0.86 | 0.80 |
| 26mm | 2.31 | 1.92 | 1.65 | 1.44 | 1.28 | 1.15 | 1.05 | 0.96 | 0.89 | 0.82 | 0.77 |
| 27mm | 2.22 | 1.85 | 1.59 | 1.39 | 1.23 | 1.11 | 1.01 | 0.93 | 0.85 | 0.79 | 0.74 |
| 28mm | 2.14 | 1.79 | 1.53 | 1.34 | 1.19 | 1.07 | 0.97 | 0.89 | 0.82 | 0.77 | 0.71 |
| 29mm | 2.07 | 1.72 | 1.48 | 1.29 | 1.15 | 1.03 | 0.94 | 0.86 | 0.80 | 0.74 | 0.69 |
| 30mm | 2.00 | 1.67 | 1.43 | 1.25 | 1.11 | 1.00 | 0.91 | 0.83 | 0.77 | 0.71 | 0.67 |
